FD-10S FD-10T FD-10P FD-10PT FD-12S FD-I2T FD-12P FD-12PT FD-18S FD-18T FD-18P FD-18PT
Faithful
Introduction:
Freeze dryer is widely applied in pharmaceutical industry, biotechnology industry, biological science industry, materials science industry, chemical industry, food andagriculture industry etc.
It is used to produce vaccines, drugs and permanentlystore biological tissues/organs.
Features:
1. 7 colorful touch panel,can display the productsamples temperature,cold trap temperatureand vacuum etc in digitaland curve.
2. Touch panel with tiltdesign conforms toergonomics and operatemore
3. Optional for gas interface:can inject inert gas
4. Optional for Cold trapelectrical heating defrostfunction Optional for rackheating which is help totest in production Eutectic point testing, it can have sublimation temperature.
Introduction:
Freeze dryer is widely applied in pharmaceutical industry, biotechnology industry, biological science industry, materials science industry, chemical industry, food andagriculture industry etc.
It is used to produce vaccines, drugs and permanentlystore biological tissues/organs.
Features:
1. 7 colorful touch panel,can display the productsamples temperature,cold trap temperatureand vacuum etc in digitaland curve.
2. Touch panel with tiltdesign conforms toergonomics and operatemore
3. Optional for gas interface:can inject inert gas
4. Optional for Cold trapelectrical heating defrostfunction Optional for rackheating which is help totest in production Eutectic point testing, it can have sublimation temperature.
Model | FD-10S | FD-10T | FD-10P | FD-10PT | FD-12S | FD-12T | FD-12P | FD-12PT | FD-18S | FD-18T | FD-18P | FD-18PT |
Type | Standard | Stoppering | Standard | Standard | Standard | Stoppering | Standard | Standard | Standard | Stoppering | Standard | Standard |
chamber with | 8 port | chamber with | chamber with | |||||||||
Final condenser temp(C) | -55 | -55 | -55 | -55 | -55 or -80 | -55 or -80 | -55 or -80 | -55 or -30 | -55 or -80 | -55 or -80 | -55 or -80 | -55 or -80 |
Condenser volume (L) | 9 | 9 | 23 | |||||||||
Freeze drying area (m2) | 0.12 | 0.09 | 0.12 | 0.09 | 0.12-0.18 | 0.09 | 0.12-0.18 | 0.09 | 0.18-0.27 | 0.135 | 0.18-0.27 | 0.135 |
Ice condenser capacity | 3 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 |
Qty of shelf | 4 | 3 | 4 | 3 | 4 | 3 | 4 | 3 | 4 | 3 | 4 | 3 |
Material loadãng | 300 | 300 | 450 | |||||||||
Material loading capacity | 1200 | 900 | 1200 | 900 | 1200 | 900 | 1200 | 900 | 1800 | 1350 | 1800 | 1350 |
Manifold | 1 | 8 pieces | 8 pieces | 8 pieces | 8 pieces | ! | / | 8 pieces | 8 pieces | |||
USB Interface | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
Vacuum Degree (Pa) | <10pa | |||||||||||
Freeze drying time (h) | 24 | |||||||||||
Drying | Transparent acrylic | |||||||||||
Vacuum Pump | Speed: 2L/S | |||||||||||
Control System | Microprocessor, touch screen | |||||||||||
Power supply (V/Ez) | 220V/ 50Hz,60Hz | |||||||||||
Exterior dimension | 582*541*374/684 | 480*630*920/1370 | 560*710*950/1390 | |||||||||
Penicillin bottle φ22 | 260 | 195 | 260 | 195 | 360 | 270 | ||||||
Penicillin bottle φ16 | 480 | 360 | 480 | 360 | 740 | 555 | ||||||
Penicillin bottle φ12 | 920 | 690 | 920 | 690 | 1320 | 990 |
Model | FD-10S | FD-10T | FD-10P | FD-10PT | FD-12S | FD-12T | FD-12P | FD-12PT | FD-18S | FD-18T | FD-18P | FD-18PT |
Type | Standard | Stoppering | Standard | Standard | Standard | Stoppering | Standard | Standard | Standard | Stoppering | Standard | Standard |
chamber with | 8 port | chamber with | chamber with | |||||||||
Final condenser temp(C) | -55 | -55 | -55 | -55 | -55 or -80 | -55 or -80 | -55 or -80 | -55 or -30 | -55 or -80 | -55 or -80 | -55 or -80 | -55 or -80 |
Condenser volume (L) | 9 | 9 | 23 | |||||||||
Freeze drying area (m2) | 0.12 | 0.09 | 0.12 | 0.09 | 0.12-0.18 | 0.09 | 0.12-0.18 | 0.09 | 0.18-0.27 | 0.135 | 0.18-0.27 | 0.135 |
Ice condenser capacity | 3 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 |
Qty of shelf | 4 | 3 | 4 | 3 | 4 | 3 | 4 | 3 | 4 | 3 | 4 | 3 |
Material loadãng | 300 | 300 | 450 | |||||||||
Material loading capacity | 1200 | 900 | 1200 | 900 | 1200 | 900 | 1200 | 900 | 1800 | 1350 | 1800 | 1350 |
Manifold | 1 | 8 pieces | 8 pieces | 8 pieces | 8 pieces | ! | / | 8 pieces | 8 pieces | |||
USB Interface | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
Vacuum Degree (Pa) | <10pa | |||||||||||
Freeze drying time (h) | 24 | |||||||||||
Drying | Transparent acrylic | |||||||||||
Vacuum Pump | Speed: 2L/S | |||||||||||
Control System | Microprocessor, touch screen | |||||||||||
Power supply (V/Ez) | 220V/ 50Hz,60Hz | |||||||||||
Exterior dimension | 582*541*374/684 | 480*630*920/1370 | 560*710*950/1390 | |||||||||
Penicillin bottle φ22 | 260 | 195 | 260 | 195 | 360 | 270 | ||||||
Penicillin bottle φ16 | 480 | 360 | 480 | 360 | 740 | 555 | ||||||
Penicillin bottle φ12 | 920 | 690 | 920 | 690 | 1320 | 990 |
