FSF-(X) Fume hood

FSF-(X) Fume hood

Product Classification

1. UV lamp for sterilization.

2. Motorized front glass window.

3. Adjustable air speed: 9 levels.

4. Alarm when filter working time 3500 hours.

5. With air velocity memory function in case of power failure.

6. Back side air compensation, to avoid turbulence in work area.

7. 10°slope front ergonomics design, fatigue-free working posture.

8. Microprocessor control system, LED display shows filter working time .

9. Transparent side glass windows maximize light and visibility inside the cabinet, providing a bright and open working environment.

Faithful Technology Park, No.26 Road, East Development

Zone, Huanghua, Cangzhou, Hebei Province, China 061100
86-317-5337349
86-317-5328349
sales@faithful.cc / info@faithful.cc

Faithful has established enviable reputation for its ability to design and manufacture high quality products.

冀公网安备13098302131132

Model	FSF1000(X)	FSF1200(X)	FSF1500(X)	FSF1800(X)
External Size (WDH)	10008402150mm	12008402150mm	16008402150mm	18008402150mm
Internal Size (WDH)	880730745mm	1080730745mm	1380730745mm	1680730745mm
Work Surface Height	750mm
Max Opening	520mm
Blower	Built-in centrifugal blower; Speed adjustable with 9 levels
Air Velocity	0.3-0.8m/s
Noise	≤60dB
Fluorescent Lamp	18W*1	18W*1	36W*1	36W*1
UV Lamp	Emission of 253.7 nanometers fo most efficient decontamination
Front Window	Motorized; 5 mm toughened glass, anti-UV
Material	Exterior:Cold-rolled steel with anti-bacteria powder coating.
	Work Table:Chemical resistant phenolic resin
Power Supply	AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Consumption	400W	400W	500W	500W
Standard Accessory	Water tap, Gas tap, Water sink, Base stand, UV lamp*2, Fluorescent lamp. FH1000(X) with one
	waterproof socket consumption not more than 500W, the rest models with two waterproof sockets
	consumption not more than 500W, 4 meters exhaust duct, Active carbon filter, Foot switch
Gross Weight	230kg	253kg	280kg	340kg
Package Size (WDH)	123011201680mm	135011201680mm	165011201680mm	195011201680mm
