FSF-150YDC FSF-200YDC FSF-280YDC FSF-400YDC
FAITHFUL
Product Description
1. Sterilizing course automatic sterilization controlled,easy to operate.
2. With drying function,suitable dressing drying.
3. With over-temperature,over-pressure auto-protect device.
4. The door opening mechanism cannot be operated until the pressure in the chamber is reduced to 0.027MPa.It can't be start on if the door doesn't close well.
5. The safety value will be open automatically when the inner pressure over 0.24MPa,and the steam be exhausting to the water tank.
6. The power will be cut-off automatically,cut-off the water and alarm when the machine lacking water.
7. Fully stainless steel structure.
Product Description
1. Sterilizing course automatic sterilization controlled,easy to operate.
2. With drying function,suitable dressing drying.
3. With over-temperature,over-pressure auto-protect device.
4. The door opening mechanism cannot be operated until the pressure in the chamber is reduced to 0.027MPa.It can't be start on if the door doesn't close well.
5. The safety value will be open automatically when the inner pressure over 0.24MPa,and the steam be exhausting to the water tank.
6. The power will be cut-off automatically,cut-off the water and alarm when the machine lacking water.
7. Fully stainless steel structure.
| Model | FSF-150YDC | FSF-200YDC | FSF-280YDC | FSF-400YDC | |||
| Sterilizing chamber | 150L | 200L | 280L | 400L | |||
| Volume | φ440×850mm | φ515×1000mm | φ600×1000mm | φ700×1100mm | |||
| working pressure | 0.22MPa | ||||||
| working temperature | 134℃ | ||||||
| Adjustment of | 40℃- 134℃ | ||||||
| temperature | |||||||
| Time of sterilization | 0-99 min | ||||||
| Time of drying | 0-99 min | ||||||
| Heat average | ≤±2℃ | ||||||
| Power | 9KW/380V 50Hz | 9KW/380V 50Hz | 12KW/380V 50Hz | 18KW/380V 50Hz | |||
| Dimension | 1400×600×1300 | 1400×670×1650 | 1400×770×1780 | 1430×880×1830 | |||
| Transport dimension | 1550×750×1850 | 1560×820×1850 | 1680×920×2100 | 1600×1050×2100 | |||
| G.W/N.W | 320/240 KG | 350/260 KG | 465/365 KG | 530/420 KG | |||
| Model | FSF-150YDC | FSF-200YDC | FSF-280YDC | FSF-400YDC | |||
| Sterilizing chamber | 150L | 200L | 280L | 400L | |||
| Volume | φ440×850mm | φ515×1000mm | φ600×1000mm | φ700×1100mm | |||
| working pressure | 0.22MPa | ||||||
| working temperature | 134℃ | ||||||
| Adjustment of | 40℃- 134℃ | ||||||
| temperature | |||||||
| Time of sterilization | 0-99 min | ||||||
| Time of drying | 0-99 min | ||||||
| Heat average | ≤±2℃ | ||||||
| Power | 9KW/380V 50Hz | 9KW/380V 50Hz | 12KW/380V 50Hz | 18KW/380V 50Hz | |||
| Dimension | 1400×600×1300 | 1400×670×1650 | 1400×770×1780 | 1430×880×1830 | |||
| Transport dimension | 1550×750×1850 | 1560×820×1850 | 1680×920×2100 | 1600×1050×2100 | |||
| G.W/N.W | 320/240 KG | 350/260 KG | 465/365 KG | 530/420 KG | |||
