DK-98-IV
FAITHFUL
Product Description:
1.Using innovative design structure, effectively prevent steam leakage.
2.Intelligent temperature control instrument with high brightness digital display, light-touch type key has the advantages of simple operation and high precision temperature control.
3.Shell, interior and cover of the product are all made of transparent engineering plastics, can clearly see the object to be heated.
4.power off when water shortage to ensure the safe operation of the product.
Product Description:
1.Using innovative design structure, effectively prevent steam leakage.
2.Intelligent temperature control instrument with high brightness digital display, light-touch type key has the advantages of simple operation and high precision temperature control.
3.Shell, interior and cover of the product are all made of transparent engineering plastics, can clearly see the object to be heated.
4.power off when water shortage to ensure the safe operation of the product.
Model | DK-98-IV | ||||
Capacity | 9L | 2.6L | 6L | 12L | 20L |
Voltage (V) | 200-240V/100-120V | 200-240V/100-120V | 200-240V/100-120V | 200-240V/100-120V | 200-240V/100-120V |
Power (kW) | 0.8 | 0.4 | 0.5 | 1.0 | 1.5 |
Temp. Motion (℃) | ±0.5 | ±0.5 | ±0.5 | ±0.5 | ±0.5 |
Temp. Range (℃) | Rt+5~100 | ||||
Temp. Sensitivity (℃) | ≤±1 | ≤±1 | ≤±1 | ≤±1 | ≤±1 |
Shelves Height (mm) | 100mm | 100mm | 100mm | 150mm | 100mm |
Shelves Holes Diameter | ¢18.7 *48mm | ¢18.7 *16mm | ¢18.7 *32mm | ¢18.7 *48mm | ¢18.7 *96mm |
Inner Chamber Size (L*W*H) | 280 x 220 x150 | 143*130*150 | 290*145*150 | 285*225*200 | 485*285*150 |
Exterior Size (L*W*H) | 400 x260x 190 | 254*190*193 | 401*190*193 | 401*276*242 | 610*338*200 |
Packing Size (L*W*H) | 450 x350 x270 | 295*270*275 | 457*270*275 | 450*350*300 | 640*410*230 |
N.W. (KG) | 3.5 | 2.1 | 3.1 | 3.9 | 6 |
G.W. (KG) | 5 | 2.7 | 3.8 | 4.8 | 8.5 |
Model | DK-98-IV | ||||
Capacity | 9L | 2.6L | 6L | 12L | 20L |
Voltage (V) | 200-240V/100-120V | 200-240V/100-120V | 200-240V/100-120V | 200-240V/100-120V | 200-240V/100-120V |
Power (kW) | 0.8 | 0.4 | 0.5 | 1.0 | 1.5 |
Temp. Motion (℃) | ±0.5 | ±0.5 | ±0.5 | ±0.5 | ±0.5 |
Temp. Range (℃) | Rt+5~100 | ||||
Temp. Sensitivity (℃) | ≤±1 | ≤±1 | ≤±1 | ≤±1 | ≤±1 |
Shelves Height (mm) | 100mm | 100mm | 100mm | 150mm | 100mm |
Shelves Holes Diameter | ¢18.7 *48mm | ¢18.7 *16mm | ¢18.7 *32mm | ¢18.7 *48mm | ¢18.7 *96mm |
Inner Chamber Size (L*W*H) | 280 x 220 x150 | 143*130*150 | 290*145*150 | 285*225*200 | 485*285*150 |
Exterior Size (L*W*H) | 400 x260x 190 | 254*190*193 | 401*190*193 | 401*276*242 | 610*338*200 |
Packing Size (L*W*H) | 450 x350 x270 | 295*270*275 | 457*270*275 | 450*350*300 | 640*410*230 |
N.W. (KG) | 3.5 | 2.1 | 3.1 | 3.9 | 6 |
G.W. (KG) | 5 | 2.7 | 3.8 | 4.8 | 8.5 |
