FAITHFUL
High quality SiC heater
The upper door and the side door can be customized to keep the operator away from the heat source
50 segments programmable and PID auto control
With over-heat alarm function
Cooling fan can reduce the temperature of the casing less than 60 ℃
Model | Max | Work Temp.(°C) | Chamber size | Volume (L) | Power (kW) | Phase | Thermocouple |
FSF-14S-1 | 1400 | 1300 | 100*100*100 | 1 | 1 | 1 | S type |
FSF-14S-2 | 1400 | 1300 | 120*120*130 | 2 | 2 | 1 | S type |
FSF-14S-3 | 1400 | 1300 | 150*150*150 | 3 | 3 | 1 | S type |
FSF-14S-5 | 1400 | 1300 | 150*150*200 | 5 | 4 | 1 | S type |
FSF-14S-8 | 1400 | 1300 | 200*200*200 | 8 | 5 | 1 | S type |
FSF-14S-12 | 1400 | 1300 | 200*200*300 | 12 | 7 | 1 | S type |
FSF-14S-27 | 1400 | 1300 | 300*300*300 | 27 | 9 | 1 | S type |
FSF-14S-36 | 1400 | 1300 | 300*300*400 | 36 | 11 | 3 | S type |
FSF-14S-64 | 1400 | 1300 | 400*400*400 | 64 | 18 | 3 | S type |
FSF-14S-125 | 1400 | 1300 | 500*500*500 | 125 | 27 | 3 | S type |
FSF-14S-216 | 1400 | 1300 | 600*600*600 | 216 | 40 | 3 | S type |
FSF-14S-512 | 1400 | 1300 | 800*800*800 | 512 | 70 | 3 | S type |
FSF-14S-729 | 1400 | 1300 | 900*900*900 | 729 | 88 | 3 | S type |
FSF-14S-1000 | 1400 | 1300 | 1000*1000*1000 | 1000 | 110 | 3 | S type |
