FSF-5V316
FAITHFUL
Fast pull down: Real forced air cooling system
Temperature simulation box: Accurately detect the temperature of storage
Suction circulation system: Big fans for better uniformity
Universal castor wheels: Proven heavy-duty lockable castors
Lockable doors: Standard locks with keys
High-quality steel materials: Antibacterial and corrosion resistant
Precise temp. Control: Temp. control accurate to 0.1C
4 types of alarm : Audible and visual alarms
Variable space: Height adjustable shelves
Eco-friendly: CFC-free refrigerant and energy-saving
Performance | Refrigeration System | Alarms | |||
Cooling method | Forced Air Cooling | Refrigerant | R290 | High/low temperature | Y |
Defrost | Auto | Capacity(L/cu.ft) | 316/11.15 | Power failure | Y |
Shelf/drawer | 6/1 | Temp. controller | Microprocessor | Thermostat (sensor) failure | Y |
Temperature range | 2℃~8℃ | Sensor | NTC | Door ajar | Y |
Ambient temperature | 10~32℃ | Display | LED Digital display | Power failure alarm(For controller) | 8H |
Noise(db) | 48 | External material | SPCC sprayed steel | Remote alarm port | Y |
Door Type | Heating Glass Door | Internal material | SPCC sprayed steel | ||
Electrical Data | Dimensions | Other | |||
Voltage frequency | 220V 50/60Hz or 110V/60Hz | Package size(W*D*H) | 717*682*2035(mm) | USB Port | Optional |
Power(W) | 286W | Exterior size(W*D*H) | 640×554×1925(mm) | Access port QTY/Dia. | 1/25mm |
Current(A) | 1.62A | Interior size(W*D*H) | 540*425*1380(mm) | Data logger | Optional |
Power consumption | 3.29 kWh/24h | NW/GW(kg) | 101/122 | RS485/232 port | Optional |
