Technical Specification:
Application: Light- to heavy-weight materials
Stitch Type: 1-needle overlock
Max. Sewing Speed: 7,000 sti/min
Stitch Length: 0.6–3.8 mm (max. 4.5 mm)
Over-Edging Width: 1.5 mm, 4.0 mm
Differential Feed Ratio: Gathering: 1:2 standard (machine capable up to 1:4 max.) / Stretching:
(max. 1:0.6)
Needle Bar Stroke: 24.5 mm
Max. Lift of Presser Foot: 7 mm
Max. Presser Foot Pressure: 63.7 N (6.5 kgf)
Lubrication: Automatic (The needle bar mechanism and upper looper mechanism do not require
lubrication.)
