SPECIFICATIONS
Main unit：Fully sealed metal chamber
Dimensions: W335xH475 xD340mm
Weight : 25kg
Power Source: 100-240 V,50-60Hz
System configuration: Main Unit only. (PC and Monitor are sold separately ， Windows 11compatible)
Software: Software for colony count
Operating environment: 10-35°C, 20-80 % humidity
Color CMOS camera: 8.5MP，Single pixel size 1.67x1.67µm
Fixed focus lens: Resolution 150lp/mm, Focal Length 8mm, F1.4~F16，C-Mount
Resolution: smallest detectable colony is 0.05 mm
Lighting：upper reflective lighting，Lower lighting（dark field or white background）
Automatic colony counting: Pour and spread plates; filters & 3M Petrifilm
Counting on Petri dishes: Ø 55 mm - Ø 90 mm
Measurement time: 1 to 3 seconds per petri dish. Depends on PC performance and measurement conditions.
Counting: Automatic with manual control
Separate touching colonies: Automatic or manual mode
Colony selection: Counting according to color, size, shape "Add"/"Delete": Counting result be corrected manually by using the mouse. Automatic rejection of impurities: According to the difference between colonies and impuritiesin shape, size and color.
Measurement: Automatic measuring area, perimeter, diameter, roundness etc.; manual measuring Line, Angle, Rectangle, Circular, Arc, Curve
Image Processing：Image adaptive enhancement, RGB Component Adjust, Sharpen, Smooth, Filter, Edge Filters, Morphological Filters, Segmentation
Data Handling: Database for storage of images and results with data query, reporting; data transfer capabilities
User security: Password protection of configuration
