Technical Specification:
Application: Standard
Lubrication: Semi-dry head (Hook: minute-quantity lubrication)
Max. sewing speed: 3,200sti/min (at the time of delivery: 2,700sti/min)*
Sewing area: 30mm (L) × 40mm (W)
Stitch length: 0.1~10mm (0.1mm step)
Needle bar stroke: 41.2mm
Lift of the work clamp foot: Standard 13mm (17mm when the reverse-rotation needle-up function)
Auto-lifter: Provided as standard (stepping motor type)
Needle thread tension: Spring type dial thread tension controller
Needle (at the time of delivery): DP × 5 (#14)
Hook: Standard shuttle hook
Number of stitches that can be stored in memory: Max. 20,000 stitches
Number of standard patterns: 51 patterns
Number of data that can be input: 200 patterns
Enlarging / Reducing facility: 20~200% (1% step), Pattern enlargement / reduction can be done by
increasing / decreasing the stitch length
Memory medium: Internal-organs memory
Bobbin thread counter: Provided as standard (up / down method)
Sewing machine motor: Compact AC servomotor (direct-drive system)
Power supply / Power consumption: Single-phase 200~240V / 250VA
