Max. swing dia. of work piece | 250mm |
Max. distance between centers | 650mm |
Working Surface of table | 940*135mm |
Max. longitudinal travel of table | 480mm |
Max. swing angle of table | ±60° |
Max travel of wheel head cross vertical | 230mm |
Max. swing angle of wheel head in horizontal plane in vertical plane | 360° |
Max. swing angle of wheel head in the longitudinal plane in vertical plane: | 30°±15 |
The end taper of the spindle | MT 3 |
Main motor power | 50Hz,0.75/1.1KW， |
The Speed of Grinding wheel | 1400/ 2800rpm |
The speed of Motor | 3050/ 6095RMP |
The Motor of Cylindrical grinding attachment | 50Hz,0.12KW |
The size of the machine | 1460*1102*1240mm |
The weight of the machine | 1000kg |
