D-160 Handheld Homogenizer

Portable, lightweight with ergonomic design ideal for manual operations

Processing volumes from 0.1-50mL or 1-250mL

Variable speed from 8,000 to 32,000 rpm

316L stainless steel shafts are fully autoclavable

Interchangeable shafts for easy dismantling and cleaning

Faithful Technology Park, No.26 Road, East Development

Zone, Huanghua, Cangzhou, Hebei Province, China 061100
86-317-5337349
86-317-5328349
sales@faithful.cc / info@faithful.cc

Faithful has established enviable reputation for its ability to design and manufacture high quality products.

冀公网安备13098302131132

Model	D-160
Speed range	8000-32000rpm
Max linear velocity	6.3、10、14 m/sec
Speed level	10 stage
Working volume [H20]	0.1-50mL (Dispersing shaft DS-160/5)
	1-150mL (Dispersing shaft DS-160/7)
	1-250mL (Dispersing shaft DS-160/10)
Max. viscosity	5,000mPas
Material of Dispersing Shaft	SS 316L stainless steel, PTFE
Noise Level	72 dB(A)
Protection class	IP20
Voltage,Frequency	110-120V/60Hz220-240V/50-60Hz
Power	160W
Motor Type	AC carbon brush motor
Dimension [WxDxH]	45mm x 55mm x 190mml
Permissible ambient temperature and humidity	0-40°C, 85%RH

Model	D-160
Speed range	8000-32000rpm
Max linear velocity	6.3、10、14 m/sec
Speed level	10 stage
Working volume [H20]	0.1-50mL (Dispersing shaft DS-160/5)
	1-150mL (Dispersing shaft DS-160/7)
	1-250mL (Dispersing shaft DS-160/10)
Max. viscosity	5,000mPas
Material of Dispersing Shaft	SS 316L stainless steel, PTFE
Noise Level	72 dB(A)
Protection class	IP20
Voltage,Frequency	110-120V/60Hz220-240V/50-60Hz
Power	160W
Motor Type	AC carbon brush motor
Dimension [WxDxH]	45mm x 55mm x 190mml
Permissible ambient temperature and humidity	0-40°C, 85%RH
