Technical Specification:
Application: Medium-weight
Hook: Vertical Axis Regular Hook
Lubrication: Semi-dry/hook section: Minute Quantity Lubrication
Max. Sewing Speed: 3,000 Stitches per Minute
Distance from needle to Machine Arm: 120mm x 266mm x 87mm
Feed system Changeover between the Needle: Feed and Bottom Feed
Max. Stitch Length: 5mm
Needle Bar Stroke: 33.4mm
Thread: Take-Up Slide Type
Lift of the Presser Foot by Hand: 7mm
Lift of the Presser Foot by Knee: 13mm
Oiling Method: Eco-oil Method (Circulation Type), Clean oil Method
Tank Capacity: 280cm
Lubricating Oil: Juki New Defrix Oil no.1 (equivalent to ISO VG7)
Needle: DPx5(#10) #9~#16
