Drug Stability Test Chamber

Home » Product » Lab Equipment » Incubator » Drug Stability Test Chamber » Drug Stability Test Chamber

All
Product Name
Product Keyword
Product Model
Product Summary
Product Description
Multi Field Search

Product Classification

Model:
FS-500SD, FS-800SD, FS-1000SD, FS-1500SD
Brand:
FAITHFUL

1. The working chamber is made of SUS304 mirror-finish stainless steel, featuring strong corrosion resistance, long service life, and

rounded corners for easy cleaning. Double-layer door structure: inner door is high-quality tempered glass for convenient sample

observation; outer door is equipped with magnetic rubber strips for easy opening/closing and excellent sealing.

2. The control panel adopts a 7.0-inch color touch screen with user-friendly software and graphical display interface, enabling easy

and intuitive setting, modification and query of temperature, humidity and other parameters. Functions include scheduled start-up,

historical data curve query, and U-disk data export.

3. Standard mobile APP remote control function for remote monitoring, parameter viewing and setting modification, with

synchronized audit trail. Electronic door lock is optional for easier management.

4. Key components such as temperature sensor, humidity sensor and compressor are imported, ensuring long-term stable, safe and

reliable operation.

5. Air circulation system: rear-mounted fan with unique air duct design, delivering uniform temperature distribution inside the

working chamber.

6. Heating method: electric heating system with independent over-temperature protection, which automatically cuts off heating when

temperature exceeds the set value to ensure safety.

7. Humidification method: built-in humidification system with small humidification particles and low water consumption, equipped

with automatic water supply and water shortage alarm. Water supply mode: automatic circulating water supply system to prevent

mold growth in the water supply system from affecting the test.

8. Cooling method: low-energy design with dual inverter compressor cooling unit. If one cooling system fails, the system

automatically switches to the backup one and alarms to protect samples.

9. Manufactured in compliance with GMP, FDA, ICH and relevant requirements of the Chinese Pharmacopoeia.

10. Technical Specifications: Refer to GB/T 10586-2006.

Item		FS‑500SD	FS‑800SD	FS‑1000SD	FS‑1500SD
Circulation Mode		Forced convection, rear microplate front air supply
Performance	Operating Temperature Range	10~65℃	10~65℃	10~65℃	10~65℃
	Temperature Resolution	0.1℃	0.1℃	0.1℃	0.1℃
	Temperature Fluctuation	±0.5℃	±0.5℃	±0.5℃	±0.5℃
	Temperature Uniformity	±1.0℃	±1.0℃	±1.0℃	±1.0℃
	Humidity Control Range	15%~95%RH	15%~95%RH	15%~95%RH	15%~95%RH
	Humidity Fluctuation	±3% RH	±3% RH	±3% RH	±3% RH
Structure	Working Chamber	SUS304 mirror‑finish stainless steel	SUS304 mirror‑finish stainless steel	SUS304 mirror‑finish stainless steel	SUS304 mirror‑finish stainless steel
	Outer Shell	Cold‑rolled steel plate with electrostatic spraying	Cold‑rolled steel plate with electrostatic spraying	Cold‑rolled steel plate with electrostatic spraying	Cold‑rolled steel plate with electrostatic spraying
	Insulation Layer	Polyurethane	Polyurethane	Polyurethane	Polyurethane
	Heater	Stainless steel heating tube	Stainless steel heating tube	Stainless steel heating tube	Stainless steel heating tube
	Compressor	Imported brand air‑cooled inverter compressor	Imported brand air‑cooled inverter compressor	Imported brand air‑cooled inverter compressor	Imported brand air‑cooled inverter compressor
	Refrigerant	R134A	R134A	R134A	R134A
	Defrosting Structure	Automatic	Automatic	Automatic	Automatic
Controller	Humidity Control Mode	Automatic	Automatic	Automatic	Automatic
	Temperature Control Mode	24‑segment program	24‑segment program	24‑segment program	24‑segment program
	Temperature Setting Mode	Touch screen setting	Touch screen setting	Touch screen setting	Touch screen setting
	Temperature Display	7.0‑inch true color touch screen	7.0‑inch true color touch screen	7.0‑inch true color touch screen	7.0‑inch true color touch screen
Operation Functions		Fixed value operation, timed operation, auto stop / scheduled start, program operation	Fixed value operation, timed operation, auto stop / scheduled start, program operation	Fixed value operation, timed operation, auto stop / scheduled start, program operation	Fixed value operation, timed operation, auto stop / scheduled start, program operation
	Program Mode	Standard	Standard	Standard	Standard
Sensor		Pt100 temperature sensor, imported chip humidity sensor	Pt100 temperature sensor, imported chip humidity sensor	Pt100 temperature sensor, imported chip humidity sensor	Pt100 temperature sensor, imported chip humidity sensor
Additional Functions		Scheduled start, historical temperature/humidity curve query, U‑disk data storage/export, deviation correction, menu button lock, power‑off compensation, power‑off memory, loop self‑diagnosis, intelligent defrosting	Scheduled start, historical temperature/humidity curve query, U‑disk data storage/export, deviation correction, menu button lock, power‑off compensation, power‑off memory, loop self‑diagnosis, intelligent defrosting	Scheduled start, historical temperature/humidity curve query, U‑disk data storage/export, deviation correction, menu button lock, power‑off compensation, power‑off memory, loop self‑diagnosis, intelligent defrosting	Scheduled start, historical temperature/humidity curve query, U‑disk data storage/export, deviation correction, menu button lock, power‑off compensation, power‑off memory, loop self‑diagnosis, intelligent defrosting
Safety Device		Over‑temperature automatically cuts off heating; long‑term under‑temperature cuts off cooling system to protect samples; loop self‑diagnosis	Over‑temperature automatically cuts off heating; long‑term under‑temperature cuts off cooling system to protect samples; loop self‑diagnosis	Over‑temperature automatically cuts off heating; long‑term under‑temperature cuts off cooling system to protect samples; loop self‑diagnosis	Over‑temperature automatically cuts off heating; long‑term under‑temperature cuts off cooling system to protect samples; loop self‑diagnosis
Dimensions	Inner Size (WDH mm)	6006001300	13405001200	14005101400	15007101400
	Outer Size (WDH mm)	85510502000	15959501900	16559602100	175511602100
	Packing Size (WDH mm)	97511702200	171510702100	177210802300	175512802300
	Internal Volume	468L	800L	1000L	1500L
	Shelf Load Capacity	20kG	20kG	20kG	20kG
	Shelf Layers	14 shelf	12 shelf	16 shelf	16 shelf
	Shelf Spacing	50mm	50mm	50mm	50mm
Power Supply (50/60Hz) Rated Current		AC220V/10.4A	AC220V/13.6A	AC220V/14.5A	AC220V/18.2A
Net/Gross Weight (kg)		320/400	400/580	440/530	510/630
Accessories	Shelves	4pcs	4pcs	4pcs	4pcs
	Shelf Brackets	8pcs	8pcs	8pcs	8pcs
Optional Configurations		Extra shelves, USB communication interface & host computer software, electronic door lock	Extra shelves, USB communication interface & host computer software, electronic door lock	Extra shelves, USB communication interface & host computer software, electronic door lock	Extra shelves, USB communication interface & host computer software, electronic door lock
