Product Description：
The ethylene oxide sterilizer is mainly through its non-specific alkylation
with genetic materials such as protein and DNA/RNA in microorganisms,
resulting in the denaturation of proteins and genetic materials, and finally
the death of microorganisms due to blocked metabolism.
Product Description：
The ethylene oxide sterilizer is mainly through its non-specific alkylation
with genetic materials such as protein and DNA/RNA in microorganisms,
resulting in the denaturation of proteins and genetic materials, and finally
the death of microorganisms due to blocked metabolism.
Model | SQ-H40 | SQ-H80 | SQ-H120 | SQ-H220 | SQ-H330 |
Product Form | Desktop | Manual door vertical |
Heating Method | Electric heating |
Temperature Display | 3.5 inch LCD display | LCD touch screen |
Sterilization Chamber Material | USU304 stainless steel |
Outer Box Material | ABS plastic | Carbon steel baking powder (thickness 1.8mm) |
Temperature During Sterilization | 50℃±3℃ | 50℃ |
Working Pressure | -60kpa |
Highest Anti-stress Value | -140kpa | -80kpa | -80kpa | -80kpa | -80kpa |
Sterilization Humidity | 45%-80% | 45%-75% |
Sterilization Time | 0-99 hours adjustable |
Air Replacement | Automatic ventilation |
Control System | One-click start，Full-automatic Control System |
Vacuum System | Oil-free vacuum pump |
Seal Door | USU304 stainless steel ( thickness ≥ 2mm) | 5052 high-quality aviation aluminum (thickness ≥15mm) |
Humidification System | Pulse steam humidification | Pulse steam humidification under vacuum |
Heating System | Explosion-proof electric heating device |
Protection functions | Over-voltage and over-temperature protection functions |
Alarm System | Have high temperature alarm system, ultra low pressure alarm system |
Power | 3.3KW /AC220V/ 50Hz | 2.6kVA /AC220V/ 50Hz | 3.0kVA /AC220V/ 50Hz | 3.3kVA /AC220V/ 50Hz | 3.6kVA /AC220V/ 50Hz |
Exterior Size(L×W×H) | 730×510×410 | 795×615×1140 | 795×615×1140 | 968×800×1240 | 968×800×1400 |
Inner Tank Size(L×W×H) | φ246×450 | 585×275×422 | 585×375×472 | 705×505×552 | 760×545×712 |
Total Volume | 23L | 67L | 103L | 196L | 294L |
Weight | 56kg | 148kg | 147kg | 227kg | 227kg |
Model | SQ-H40 | SQ-H80 | SQ-H120 | SQ-H220 | SQ-H330 |
Product Form | Desktop | Manual door vertical |
Heating Method | Electric heating |
Temperature Display | 3.5 inch LCD display | LCD touch screen |
Sterilization Chamber Material | USU304 stainless steel |
Outer Box Material | ABS plastic | Carbon steel baking powder (thickness 1.8mm) |
Temperature During Sterilization | 50℃±3℃ | 50℃ |
Working Pressure | -60kpa |
Highest Anti-stress Value | -140kpa | -80kpa | -80kpa | -80kpa | -80kpa |
Sterilization Humidity | 45%-80% | 45%-75% |
Sterilization Time | 0-99 hours adjustable |
Air Replacement | Automatic ventilation |
Control System | One-click start，Full-automatic Control System |
Vacuum System | Oil-free vacuum pump |
Seal Door | USU304 stainless steel ( thickness ≥ 2mm) | 5052 high-quality aviation aluminum (thickness ≥15mm) |
Humidification System | Pulse steam humidification | Pulse steam humidification under vacuum |
Heating System | Explosion-proof electric heating device |
Protection functions | Over-voltage and over-temperature protection functions |
Alarm System | Have high temperature alarm system, ultra low pressure alarm system |
Power | 3.3KW /AC220V/ 50Hz | 2.6kVA /AC220V/ 50Hz | 3.0kVA /AC220V/ 50Hz | 3.3kVA /AC220V/ 50Hz | 3.6kVA /AC220V/ 50Hz |
Exterior Size(L×W×H) | 730×510×410 | 795×615×1140 | 795×615×1140 | 968×800×1240 | 968×800×1400 |
Inner Tank Size(L×W×H) | φ246×450 | 585×275×422 | 585×375×472 | 705×505×552 | 760×545×712 |
Total Volume | 23L | 67L | 103L | 196L | 294L |
Weight | 56kg | 148kg | 147kg | 227kg | 227kg |
