Model | SQ-XH120 | SQ-XH220 |
Product Form | Vertical |
Heating Method | Electric heating |
Temperature Display | LCD touch screen |
Material of Sterilization Room | Aluminium 5052 |
Outer Box Material | ABS board (5mm thick) spray paint |
Temperature During Sterilization | 50 ℃ |
Working Pressure | -60kpa |
Highest Anti-stress Value | -80kpa |
Humidity During Sterilization | 45% -75% |
Sterilization Time | 0-99 hours adjustable |
Vacuum Speed | Pumped to -60kpa in 5 minutes |
Air Replacement | Automatic ventilation, 5 cycles of ventilation, every 15 minutes |
Control System | Full-automatic，One-click start to finish |
Printer | Yes |
Vacuum System | Oil-free vacuum pump |
Sealed Door | 5052 high-quality aluminum (thickness ≥ 2mm) |
Heating System | Explosion-proof electric heating device |
Protection Functions | over-voltage and over-temperature protection functions |
Alarm System | high and low temperature alarm system, high and low pressure alarm system, leak rate detection alarm system, high and low humidity alarm system, sealed door detection alarm system, dosing detection alarm system |
Power-off Memory Function | Yes |
Dimensions(L×W×H) | 976×790×1715mm | 976×790×1715mm |
Liner Size(L×W×H) | 700×450×400mm | 820×510×460mm |
Effective Volume | 126L | 192L |
Power | 3.0kW /220V/ 50Hz | 3.6kVA /220V / 50Hz |
Weight | 210kg | 220kg |
