Flow Rate | 100L/min |
Wind Speed of sampling holes | 0.4m/s, basically the same as that of clean room (Isokinetic sampling) |
Accuracy of Flow rate | ±2.5% |
Principle | Anderson impact principle |
Sampling volume | 20-6000L |
Delay | 0-59 min 59 Second |
Sampling times | 1-99 times |
Interval | 10S-59 Min 59 second |
Location editing | Editable, 100 Locations |
Permissions | 3 level（Operators, Engineers, Administrators） |
Exhaust | ISO 3 |
Data storage | 20,000 group data |
Data content | Date time, location, operator, delay , number of cycles, interval time, preset volume, actual volume, status |
Data export | U disk, CSV format, can export sample data report and operation log report |
Communication | USB to serial port (MODBUS RTU protocol) |
Print | Bluetooth printer |
Display | 5 inch color touch dispaly |
Language | English、Chinese |
Power supply | 24VDC±10% |
Operating Time on Battery(h) | 6-8 Hours |
Weight & Dimension | 2.1kg，125*135*260mm（Length*Wide*Height） |
Accessory | Carry case、Charger 、Calibration certificate、U Disk |
Optional | Tripod、Printer |
