Eyepiece | Wide Field Plane-scope Eyepiece:WF10X/18mm; Wide Field Plane-scope Eyepiece:WF16X/13mm; |
Objective | 45mm DIN Achromatic objective:4x,10x,40x(s),100(s,oil) |
Head | Articuiated Free Trinocular Head, Interpupillary Distance:55-75mm;30°inclined, 360°Rotatabte; The Adjustable Height range of the Vertical Tube:10mm |
Stage | Double Layers Mechanical Stage: 140X155mm, Moving Range X-Y:70X50mm |
Condenser | ABBE Condenser:N.A.1.25;Φ2-Φ30mm Iris Diaphragm and Φ32 Filter |
Focusing Adjustment | Coaxial Coarse and Fine Focusing Adjustable Mechanism:30mm,Precision:0.002mm |
Wavelength | B(blue) excitinglighting filter system,wavelength450-490mm |
G(Green) Exciting Lighting Fiiter System, Wavelength 510-570(nm) |
Body package | 1set/ctn 42x31X52cm GW:9.3kgs |
Fluorescent attachment package | 1set/ctn 46X38X23cm G.W:6kgs |
