Eyepiece | Wide Field Plan-scope Eyepiece: WF10X |
Objective | 45mm DIN Achromatic Objective: 4X,10X,40X(S), 100(S,Oil) |
Head | Articulated Free Binocular Head, Interpupillary Distance:55-75mm; 30°Inclined, 360°Rotatable |
Stage | Double Layers Mechanical Stage: 125X125mm, Moving Range X-Y: 60X40mm |
Condenser | ABBE Condenser: N.A.1.25; Ф2-Ф30mm Iris Diaphragm and Ф32 Filter |
Focusing Adjustment | Coaxial Coarse and Fine Focusing Adjustable Mechanism: 14mm |
Illumination | Built-in Adjustable Brightness 1W LED lamp |
Optional | 1.WF16X; 2.Semi Plan Objective, Plan Objective; 3.Rechargeable Batteries |
Net Weight | 4kg |
