Eyepiece | Wide Field Plan-scope Eyepiece: WF10X/18mm |
Objective | 45mm DIN Achromatic Objective: 4X,10X,40X(S), 100(S,Oil) |
Head | Articulated Free Binocular Head, Interpupillary Distance:55-75mm;30° Inclined , 360°Rotatable |
Stage | Double Layers Mechanical Stage: 130X140mm, Moving Range X-Y: 70X50mm |
Condenser | ABBE Condenser: N.A.1.25; Ф2-Ф30mm Iris Diaphragm and Ф32 Filter |
Focusing Adjustment | Coaxial Coarse and Fine Focusing Adjustable Mechanism: 20mm, Precision:0.002mm |
Illumination | Optional: Built-in Adjustable Brightness 1W LED lamp; 6V/20W Halogen Lamp |
Optional | 1.WF10X;WF16X; 2.Semi Plan Objective, Plan Objective; 3.Rechargeable Batteries 4.Electronic Eyepiece 1.3Mp, 3.0Mp |
Net Weight | 5.6kg |
