DC0506 DC1006 DC2006 DC3006 DC4006 DC-0510 DC-1010 DC-2010 DC-3010 DC-4010 DC-0515 DC-1015 DC-2015 DC-3015 DC-4015
FAITHFUL
Fully closed compressor refrigeration, refrigeration system with overheating,overcurrent multiple protection devices.
Can be imported by constant temperature liquid in the tank; Low temperature andconstant temperature experiments can also be carried out directly in the tank.
XMT analog digital PlD automatic control system.
The inner liner and table are all stainless steel.
Optional RS232 or Rs485 communication interfaces are available fordatatransmission and remote control, enabling programmed temperature control.
Fully closed compressor refrigeration, refrigeration system with overheating,overcurrent multiple protection devices.
Can be imported by constant temperature liquid in the tank; Low temperature andconstant temperature experiments can also be carried out directly in the tank.
XMT analog digital PlD automatic control system.
The inner liner and table are all stainless steel.
Optional RS232 or Rs485 communication interfaces are available fordatatransmission and remote control, enabling programmed temperature control.
Model | Temperature Range (°C) | Temperature Fluctuation (°C) | Digital Display Resolution (°C) | Working Tank Volume (mm³) | Working Tank Opening (mm²) | Inner Tank Volume (L) | Circulating Pump Flow Rate (L/min) |
6L SERIES | |||||||
DC0506 | -5-100℃ | 0.05 | 0.01 | 250*200*150 | 180*140*150 | 6 | 6 |
DC1006 | -10-100℃ | 0.05 | 0.01 | 250*200*150 | 180*140*150 | 6 | 6 |
DC2006 | -20-100℃ | 0.05 | 0.01 | 250*200*150 | 180*140*150 | 6 | 6 |
DC3006 | -30-100℃ | 0.1 | 0.1 | 250*200*150 | 180*140*150 | 6 | 6 |
DC4006 | -40-100℃ | 0.1 | 0.1 | 250*200*150 | 180*140*150 | 6 | 6 |
10L SERIES | |||||||
DC-0510 | -5-100℃ | 0.05 | 0.01 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-1010 | -10-100℃ | 0.05 | 0.01 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-2010 | -20-100℃ | 0.05 | 0.01 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-3010 | -30-100℃ | 0.1 | 0.1 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-4010 | -40-100℃ | 0.1 | 0.1 | 250*200*200 | 180*140*200 | 10 | 6 |
15L SERIES | |||||||
DC-0515 | -5-100℃ | 0.05 | 0.01 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-1015 | -10-100℃ | 0.05 | 0.01 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-2015 | -20-100℃ | 0.05 | 0.01 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-3015 | -30-100℃ | 0.1 | 0.1 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-4015 | -40-100℃ | 0.1 | 0.1 | 300*250*200 | 235*160*200 | 15 | 6 |
20L SERIES | |||||||
DC-0520 | -5-100℃ | 0.05 | 0.01 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-1020 | -10-100℃ | 0.05 | 0.01 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-2020 | -20-100℃ | 0.05 | 0.01 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-3020 | -30-100℃ | 0.1 | 0.1 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-4020 | -40-100℃ | 0.1 | 0.1 | 235*160*280 | 280*200*280 | 20 | 6 |
30L SERIES | |||||||
DC-0530 | -5-100℃ | 0.05 | 0.01 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-1030 | -10-100℃ | 0.05 | 0.01 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-2030 | -20-100℃ | 0.05 | 0.01 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-3030 | -30-100℃ | 0.1 | 0.1 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-4030 | -40-100℃ | 0.1 | 0.1 | 400*325*230 | 310*280*230 | 30 | 13 |
Model | Temperature Range (°C) | Temperature Fluctuation (°C) | Digital Display Resolution (°C) | Working Tank Volume (mm³) | Working Tank Opening (mm²) | Inner Tank Volume (L) | Circulating Pump Flow Rate (L/min) |
6L SERIES | |||||||
DC0506 | -5-100℃ | 0.05 | 0.01 | 250*200*150 | 180*140*150 | 6 | 6 |
DC1006 | -10-100℃ | 0.05 | 0.01 | 250*200*150 | 180*140*150 | 6 | 6 |
DC2006 | -20-100℃ | 0.05 | 0.01 | 250*200*150 | 180*140*150 | 6 | 6 |
DC3006 | -30-100℃ | 0.1 | 0.1 | 250*200*150 | 180*140*150 | 6 | 6 |
DC4006 | -40-100℃ | 0.1 | 0.1 | 250*200*150 | 180*140*150 | 6 | 6 |
10L SERIES | |||||||
DC-0510 | -5-100℃ | 0.05 | 0.01 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-1010 | -10-100℃ | 0.05 | 0.01 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-2010 | -20-100℃ | 0.05 | 0.01 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-3010 | -30-100℃ | 0.1 | 0.1 | 250*200*200 | 180*140*200 | 10 | 6 |
DC-4010 | -40-100℃ | 0.1 | 0.1 | 250*200*200 | 180*140*200 | 10 | 6 |
15L SERIES | |||||||
DC-0515 | -5-100℃ | 0.05 | 0.01 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-1015 | -10-100℃ | 0.05 | 0.01 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-2015 | -20-100℃ | 0.05 | 0.01 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-3015 | -30-100℃ | 0.1 | 0.1 | 300*250*200 | 235*160*200 | 15 | 6 |
DC-4015 | -40-100℃ | 0.1 | 0.1 | 300*250*200 | 235*160*200 | 15 | 6 |
20L SERIES | |||||||
DC-0520 | -5-100℃ | 0.05 | 0.01 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-1020 | -10-100℃ | 0.05 | 0.01 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-2020 | -20-100℃ | 0.05 | 0.01 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-3020 | -30-100℃ | 0.1 | 0.1 | 235*160*280 | 280*200*280 | 20 | 6 |
DC-4020 | -40-100℃ | 0.1 | 0.1 | 235*160*280 | 280*200*280 | 20 | 6 |
30L SERIES | |||||||
DC-0530 | -5-100℃ | 0.05 | 0.01 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-1030 | -10-100℃ | 0.05 | 0.01 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-2030 | -20-100℃ | 0.05 | 0.01 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-3030 | -30-100℃ | 0.1 | 0.1 | 400*325*230 | 310*280*230 | 30 | 13 |
DC-4030 | -40-100℃ | 0.1 | 0.1 | 400*325*230 | 310*280*230 | 30 | 13 |
