Characteristics
Heating power and stirring speed is steplessadjustable.
With adjustable thermometer rack, stainlesssteel rods and the stir bar.
SH-(C) series: Ceramic Plate
SH-3D: Aluminium plate & Display controller
SH-3D(C): Ceramic plate&Display controller
Characteristics
Heating power and stirring speed is steplessadjustable.
With adjustable thermometer rack, stainlesssteel rods and the stir bar.
SH-(C) series: Ceramic Plate
SH-3D: Aluminium plate & Display controller
SH-3D(C): Ceramic plate&Display controller
Model | SH-2A | SH-2B | SH-2 | SH-3A | SH-3B | SH-3D | SH-3 |
SH-2A (C) | SH-2B (C) | SH-2 (C) | SH-3A (C) | SH-3B(C) | SH-3D(C) | SH-3 (C) |
Function | Max. Volume (ml) | - | 2000 | 2000 | - | 5000 | 5000 | 5000 |
Speed (r.p.m) | - | 100~2000 | - | 100~2000 |
Working time |
| Continuous |
Minimum revolution (r.p.m) | - | 100 | 100 | - | 100 | 100 | 100 |
Max.Temp.（℃） | 380 | - | 380 | 380 | - | 380 | 380 |
Structure | Exterior |
| Cast aluminium, Surface spraying |
Plate size(mm) | 120×120 | 170×170 |
Driving mode | - | Motor | - | Motor |
Motor power (W) | - | 10 | - | 20 |
Heating Power(kW) | 0.18 | - | 0.18 | 0.5 | - | 0.5 | 0.5 |
| Stir bar | - | PTFE | - | PTFE |
Controller | Continuous operation |
| Yes |
Setting mode | Scale |
Speed display mode | - | Scale | - | Scale |
Timer | No |
Operation function | No |
Temp. Sensor | No | Yes | No |
Specification | Exterior size (W*L*H)(mm) | 200×120×90 | 265×185x190 |
Packing size (W*L*H)(mm) | 250×180×120 | 280×210×220 |
Plate size（mm） | 120×120 | 170×170 |
Plate load | 3KG | 10KG |
Power supply（50/60Hz）Current rating | 110V or 220V |
NW/GW (kg） | 1.9/3 | 1.9/3 | 1.9/3 | 2.2/3.4 | 2.2/3.4 | 2.2/3.4 | 2.2/3.4 |
