Product Description
Stainless steel head restraints， more durable.
Digital display model, stirring has three modes: positive ，reverse ，positive and negative alternating.
Digital type: brushless motor.
SH-II-8C is new big power type, high torque, can be used for mixing mud.
Product Description
Stainless steel head restraints， more durable.
Digital display model, stirring has three modes: positive ，reverse ，positive and negative alternating.
Digital type: brushless motor.
SH-II-8C is new big power type, high torque, can be used for mixing mud.
| Model | SH-II-6 | SH-II-6C | SH-II-7C | SH-II-8C |
| Function | Max. Volume(L) | 20 | 20 | 40 | 40 |
| digital | - | LCD | LCD | LCD |
| Speed(r.p.m) | 100～2500 | 100～2500 | 100～2500 | 100～2500 |
| Working time | Continous |
| Minimum revolution (r.p.m) | 100 | 100 | 100 | 100 |
| Structure | Exterior | Plastic shell |
| Driving mode | Motor |
| Motor power (kW) | 0.06 | 0.06 | 0.08 | 0.12 |
| Controller | Continuous operation | Yes |
| Setting mode | Scale | Digital | Digital | Digital |
| Speed display mode | Scale | Digital | Digital | Digital |
| Timer | No | Yes | Yes | Yes |
| Max VIscosity | 10000 | 10000 | 15000 | 50000 |
| Specification | Exterior size (W*L*H)(mm) | 115×95×240 |
| Packing size (W*L*H)(mm) | 400×250×210 |
| Plate size（mm） | 200×300 |
| Plate load | 50KG |
| Power supply（50/60Hz）Current rating | 100～240V |
| NW/GW (kg） | 7/8 | 7/8 | 7.5/8.5 | 8/9 |
| Model | SH-II-6 | SH-II-6C | SH-II-7C | SH-II-8C |
| Function | Max. Volume(L) | 20 | 20 | 40 | 40 |
| digital | - | LCD | LCD | LCD |
| Speed(r.p.m) | 100～2500 | 100～2500 | 100～2500 | 100～2500 |
| Working time | Continous |
| Minimum revolution (r.p.m) | 100 | 100 | 100 | 100 |
| Structure | Exterior | Plastic shell |
| Driving mode | Motor |
| Motor power (kW) | 0.06 | 0.06 | 0.08 | 0.12 |
| Controller | Continuous operation | Yes |
| Setting mode | Scale | Digital | Digital | Digital |
| Speed display mode | Scale | Digital | Digital | Digital |
| Timer | No | Yes | Yes | Yes |
| Max VIscosity | 10000 | 10000 | 15000 | 50000 |
| Specification | Exterior size (W*L*H)(mm) | 115×95×240 |
| Packing size (W*L*H)(mm) | 400×250×210 |
| Plate size（mm） | 200×300 |
| Plate load | 50KG |
| Power supply（50/60Hz）Current rating | 100～240V |
| NW/GW (kg） | 7/8 | 7/8 | 7.5/8.5 | 8/9 |
