Model | FD-10ES | FD-10EP | FD-10ET | FD-10EPT |
Type |
Standard chamber |
4 port manifold |
Stoppering chamber | Stoppering chamber with 4 port manifold |
Final condenser temp (℃) | -88 |
Shelf temp (℃) | -60~+70 |
Temp.uniformity (℃) | ±1 |
Vacuum degree (Pa) | ≤0.1 |
Condenser volume (L) | 11 |
Freeze drying area (m2) | 0.1 |
Condensing capacity (Kg/24h) | 3 |
Qty of shelf | 1 |
Drying chamber volume (L) | 40 |
Material loading capacity (mL) | 3000 |
Penicillin bottle ⌀22 | 216 |
Penicillin bottle ⌀16 | 400 |
Penicillin bottle ⌀12 | 726 |
Manifold | / | 4 pieces | / | 4 pieces |
USB interface | Yes |
Drying chamber (standard) | Transparent acrylic |
Vacuum pump | Standard model: VRD-8* |
Control system | Microprocessor, touch screen |
Electrical voltage | 220V/50/60HZ |
Power (Kw) | 2.3 |
Condenser chamber dimension (WxDxHmm) | 300x438x320 |
Shelf specification (WxDxHmm) | 820×695×600/995 | 820×695×875/1075 |
