Spcifications: |
Magnetic table : |
Dimension of working surface | 500 x 200 mm |
Height | Height 65mm/335mm |
Longitudinal speed | 0 to 15 meters per min. |
Cross traverse (manual / power) | 220 mm |
Cross traverse feed |
Rate per table stroke | 0.5 to 6.0 mm. |
Grinding head: Maximum vertical movement | 225mm (Manual / power positioning) |
Distance of spindle axis above magnetic table surfacemn | 295/335 |
Grinding wheel dimensions | 200 x 20x 50 mm/ 180X13X31.75 / 200X16X31.75 |
Spindle speed | 2500/2850 rpm |
Motor: grinding spindle | 1.5KW (2HP). |
Hydraulic pump (Feed system) | 750 W /1 HP. |
Coolant pump | 400w for 440V,50 Hz, 3 phase supply. |
Machine supplied with non-electric magnetic table and overhead wheel dressing unit and a 1.5 cornt dressing |
Extra grinding wheel 200 x 20x 50 mm/ 200X16X31.75mm |
