Parameter:
Ø Sample size：38*70mm(Standard size)
Ø Actual measurement size：38*50mm(standard)
Ø Span range: span length 1~60mm，5mm、10mm、15mm、20mm、25mm、30mm、40mm、50mm,8 Adjustable 8-gear lever。
Ø Span accuracy：±0.1mm
Ø test range：（0~10000）mN
Ø Sensing accuracy: ±0.1%
Ø Resolution：0.01mN
Ø Bending angle： 1~92 º stepless
Ø Angle measurement: a single angle is measured each time, and there is stepless range of 0 ~ 90 °
ØAngular velocity control:0.5 – 50 °/sec adjustable，Three test angles and duration can be adjusted independently
Ø Angle accuracy：±0.1
Ø Measuring thickness: suitable for thickness in（0.01~5.0）mm Paper grade and other composite materials
Ø Bending time: select different bending time according to the elasticity of the material
Sample fixture: manual fixture operation, automatic reset after test
Ø Operation interface: 7inch touch screen operation interface, visual menu operation.
Ø Clamping mode: unlimited clamping, non-destructive and continuous clamping
Ø Signal output: standard computer signal output, link computer, IMT computer operating platform, can realize document editing (optional)
Ø Self calibration: the equipment can realize self calibration, with calibration tools as standard
Ø Printing output: modular integrated thermal printer
