PlD automatic temperature control.
Internal circulation can be achieved to ensure temperature uniformity.
Large LcD display, touch keys.
PlD automatic temperature control.
Internal circulation can be achieved to ensure temperature uniformity.
Large LcD display, touch keys.
| Model | Temperature Range(℃) | Digital display resolution(℃) | Temperature fluctuation（±℃） | Working Tank Volume (mm³) | Working slot opening（mm²） | Slot depth（mm） | Cyclic mode |
| CH1020T | Room temperature～80 | 0.01 | 0.05 | φ240*300 | φ170 | 300 | Internal circulation |
| PX-15T-II | Room temperature～80 | 0.01 | 0.2-0.05 | 300*250*200 | 248*160 | 200 | Internal circulation |
| PX-15T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 300*250*200 | 248*160 | 200 | Internal circulation |
| PX-18T-I | Room temperature～80 | 0.1 | 0.1 | 250*200*350 | 198*140 | 350 | Internal circulation |
| PX-18T-II | Room temperature～80 | 0.01 | 0.02-0.05 | 250*200*350 | 198*140 | 350 | Internal circulation |
| PX-18T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 250*200*350 | 198*140 | 350 | Internal circulation |
| PX-20T-I | Room temperature～80 | 0.1 | 0.1 | 300*250*300 | 248*160 | 300 | Internal circulation |
| PX-20T-II | Room temperature～80 | 0.01 | 0.02-0.05 | 300*250*300 | 248*160 | 300 | Internal circulation |
| PX-20T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 300*250*300 | 248*160 | 300 | Internal circulation |
| PX-30T-I | Room temperature～80 | 0.1 | 0.1 | 420*300*250 | 300*298 | 250 | Internal circulation |
| PX-30T-II | Room temperature～80 | 0.01 | 0.02-0.05 | 420*300*250 | 300*298 | 250 | Internal circulation |
| PX-30T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 420*300*250 | 300*298 | 250 | Internal circulation |
| PX-50T-I | Room temperature～80 | 0.1 | 0.1 | 500*350*300 | 380*348 | 300 | Internal circulation |
| PX-50T-III | Room temperature～80 | 0.001 | 0.01-0.02 | 500*350*300 | 380*348 | 300 | Internal circulation |
| Model | Temperature Range(℃) | Digital display resolution(℃) | Temperature fluctuation（±℃） | Working Tank Volume (mm³) | Working slot opening（mm²） | Slot depth（mm） | Cyclic mode |
| PX-1A | Room temperature～200 | 0.1 | 0.1 | φ300*200 | φ170 | 200 | Internal circulation |
| PX-2A | Room temperature～200 | 0.1 | 0.1 | φ300*300 | φ170 | 300 | Internal circulation |
| PX-3A | Room temperature～200 | 0.1 | 0.1 | φ300*400 | φ170 | 400 | Internal circulation |
| PX-4A | Room temperature～300 | 0.1 | 0.1 | φ300*200 | φ170 | 200 | Internal circulation |
| PX-5A | Room temperature～300 | 0.1 | 0.1 | φ300*300 | φ170 | 300 | Internal circulation |
| PX-6A | Room temperature～300 | 0.1 | 0.1 | φ300*400 | φ170 | 400 | Internal circulation |
| PX-6G | Room temperature～200 | 0.001 | 0.005-0.02 | φ300*300 | φ170 | 300 | Internal circulation |
| PX-7A | Room temperature～80 | 0.01 | 0.02-0.04 | 300*250*200 | φ170 | 200 | Internal circulation |
| PX-8A | Room temperature～80 | 0.01 | 0.02-0.04 | 300*250*300 | φ170 | 300 | Internal circulation |
| PX-9A | Room temperature～80 | 0.01 | 0.02-0.04 | 250*200*350 | φ150 | 350 | Internal circulation |
| PX-9G | Room temperature～80 | 0.001 | 0.002-0.005 | 250*200*350 | φ150 | 350 | Internal circulation |
| Model | Temperature Range(℃) | Digital display resolution(℃) | Temperature fluctuation（±℃） | Working Tank Volume (mm³) | Working slot opening（mm²） | Slot depth（mm） | Cyclic mode |
| CH1020T | Room temperature～80 | 0.01 | 0.05 | φ240*300 | φ170 | 300 | Internal circulation |
| PX-15T-II | Room temperature～80 | 0.01 | 0.2-0.05 | 300*250*200 | 248*160 | 200 | Internal circulation |
| PX-15T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 300*250*200 | 248*160 | 200 | Internal circulation |
| PX-18T-I | Room temperature～80 | 0.1 | 0.1 | 250*200*350 | 198*140 | 350 | Internal circulation |
| PX-18T-II | Room temperature～80 | 0.01 | 0.02-0.05 | 250*200*350 | 198*140 | 350 | Internal circulation |
| PX-18T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 250*200*350 | 198*140 | 350 | Internal circulation |
| PX-20T-I | Room temperature～80 | 0.1 | 0.1 | 300*250*300 | 248*160 | 300 | Internal circulation |
| PX-20T-II | Room temperature～80 | 0.01 | 0.02-0.05 | 300*250*300 | 248*160 | 300 | Internal circulation |
| PX-20T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 300*250*300 | 248*160 | 300 | Internal circulation |
| PX-30T-I | Room temperature～80 | 0.1 | 0.1 | 420*300*250 | 300*298 | 250 | Internal circulation |
| PX-30T-II | Room temperature～80 | 0.01 | 0.02-0.05 | 420*300*250 | 300*298 | 250 | Internal circulation |
| PX-30T-III | Room temperature～80 | 0.001 | 0.005-0.01 | 420*300*250 | 300*298 | 250 | Internal circulation |
| PX-50T-I | Room temperature～80 | 0.1 | 0.1 | 500*350*300 | 380*348 | 300 | Internal circulation |
| PX-50T-III | Room temperature～80 | 0.001 | 0.01-0.02 | 500*350*300 | 380*348 | 300 | Internal circulation |
| Model | Temperature Range(℃) | Digital display resolution(℃) | Temperature fluctuation（±℃） | Working Tank Volume (mm³) | Working slot opening（mm²） | Slot depth（mm） | Cyclic mode |
| PX-1A | Room temperature～200 | 0.1 | 0.1 | φ300*200 | φ170 | 200 | Internal circulation |
| PX-2A | Room temperature～200 | 0.1 | 0.1 | φ300*300 | φ170 | 300 | Internal circulation |
| PX-3A | Room temperature～200 | 0.1 | 0.1 | φ300*400 | φ170 | 400 | Internal circulation |
| PX-4A | Room temperature～300 | 0.1 | 0.1 | φ300*200 | φ170 | 200 | Internal circulation |
| PX-5A | Room temperature～300 | 0.1 | 0.1 | φ300*300 | φ170 | 300 | Internal circulation |
| PX-6A | Room temperature～300 | 0.1 | 0.1 | φ300*400 | φ170 | 400 | Internal circulation |
| PX-6G | Room temperature～200 | 0.001 | 0.005-0.02 | φ300*300 | φ170 | 300 | Internal circulation |
| PX-7A | Room temperature～80 | 0.01 | 0.02-0.04 | 300*250*200 | φ170 | 200 | Internal circulation |
| PX-8A | Room temperature～80 | 0.01 | 0.02-0.04 | 300*250*300 | φ170 | 300 | Internal circulation |
| PX-9A | Room temperature～80 | 0.01 | 0.02-0.04 | 250*200*350 | φ150 | 350 | Internal circulation |
| PX-9G | Room temperature～80 | 0.001 | 0.002-0.005 | 250*200*350 | φ150 | 350 | Internal circulation |
