Vertical Constant Temperature Shaker (LCD)
Home » Product » Lab Equipment » Shaker » Shaking Incubator » Vertical Constant Temperature Shaker (LCD)

Product Classification

Contact Us

Vertical Constant Temperature Shaker (LCD)

Vertical constant temperature oscillating equipment with multiple amplitudes
Quantity:
  • FSI-175C;FSI-335C;FSI-580C
  • FAITHFUL

Product Description

1. Imported compressors,imported bearings,servo motors.

2. Air duct design,not direct blowing,good temperature uniformity.

3.  The minimum speed is 20rpm Custom models can be done 10rpm ,and it can start and stop at ultra-low speed to protect the sample to the greatest extent.

4. Make an appointment to start the function.

5.Solenoid valve defrost function can ensure long-term low temperature operation.

6.Can be set to run forward,reverse,and alternately run.


Name

Vertical Constant Temperature Shaker (LCD)

Model

FSI-175

FSI-175C

FSI-335

FSI-335C

FSI-580

FSI-580C

Control Mode

PID microcomputer processing chip

Cycle Mode

Forced convection

Shaking Mode

Convolution

Display Mode

LCD  liquid crystaldisplay

Drive Mode

Multidimensional drive

3 Axes

4 Axes

USB data download system

Yes(optional)

Control System

(Standard mode; continuous mode; programmable mode (multi-stage temperature, speed, time control))

Rotary Speed Range(rpm)

0,20-350(Can do static training, forward and reverse)

0,20-280(Can do static training, forward and reverse)

Rotary Accuracy(rpm)

±1

Amplitude(mm)

Φ26(customizable Φ35(20-250rpm/min)、Φ50(20-2000rpm/min)

Max  Capacity (clamp)

100ml*60

or 250ml*38

or 500ml*22

or 1L*16

100ml*100

or 250ml*56

or 500ml*44

or 1L*24

250ml*90

or 500ml*72

or 1000ml*42

Max  Capacity ( stick mat)

100ml*60

or 250ml*36

or500ml*24

or 1L*16

100ml*120

or 250ml*70

or 500ml*44

or1L*24

250ml*112

or 500ml*76

or 1000ml*42

Standard   configuration

250ml*24

250ml*28  500ml*22

250ml*45  500ml*36

Plate Size(mm)

500*360

710*455

950*550

Timer Range(h/min)

0-9999(with  timing function)

Temperature Range(℃)

RT+5-65

4-65
(25℃)

RT+5-65

4-65
(25℃)

RT+5-65

4-65
(25℃)

Temperature Accuracy(℃)

±0.1

Temperature Uniformity(℃)

±0.5(37℃)

Temperature Motion(℃)

≤0.1(37℃)

Tray Quantity

(2 pieces)

External Size(mm)

700*580*1280

950*700*1280

1200*800*1630

Capacity(L)

175

335

580

Power(W)

600

850

900

1150

1100

1400

Power Supply

AC220±10%  50-60HZ

Ambient Temperature(℃)

5-30

Additional Function

Ultra-low start, adjustable start speed, automatic overspeed protection, watchdog timer, parameter memory, call recovery, refrigeration unit overload protection and call delay start, automatic defrost, upper and lower limit over temperature sound and light alarm, automatic stop when the door is opened (optional ), with lighting, ultraviolet disinfection function (optional), setting parameter view, monitoring temperature and correction of ambient temperature. Touch screen (optional)
