Product Description:
1. Automatically controlled by computer, digital display of work- ing status, touch type key.
2. Fully automatically route for water inlet, pulse vacuum, heat- ing, sterilizing, draining, exhausting, vacuum drying.
3. 3 times pulse vacuum, which make the vacuum rate as -0.081 mpa,and ensure the high extracting of inner air from
dressing, A.B type hollowed appliance.
4. With 4 fixed program for appliance, medical dressing, rub- bers and fluid, and the user
can also set the program as they
5. Equipped with the PTAT testing connector, easy to run the testing.
6. Multiple pulse vacuum drying after sterilizing, ensure the nice sterilizing.
7. Equipped with bacteria filter, ensure the sterile air enter the inner vacuum environment, avoid the second
contamination.
8. Steam-water inner circulation system: no steam discharge, and the environment for sterilizing will be clean and dry.
9. Automatically shut off with beep reminding after sterilization.
Product Description:
1. Automatically controlled by computer, digital display of work- ing status, touch type key.
2. Fully automatically route for water inlet, pulse vacuum, heat- ing, sterilizing, draining, exhausting, vacuum drying.
3. 3 times pulse vacuum, which make the vacuum rate as -0.081 mpa,and ensure the high extracting of inner air from
dressing, A.B type hollowed appliance.
4. With 4 fixed program for appliance, medical dressing, rub- bers and fluid, and the user
can also set the program as they
5. Equipped with the PTAT testing connector, easy to run the testing.
6. Multiple pulse vacuum drying after sterilizing, ensure the nice sterilizing.
7. Equipped with bacteria filter, ensure the sterile air enter the inner vacuum environment, avoid the second
contamination.
8. Steam-water inner circulation system: no steam discharge, and the environment for sterilizing will be clean and dry.
9. Automatically shut off with beep reminding after sterilization.
Model | FSF-35HV | FSF-50HV | FSF-75HV | FSF-100HV |
Capacity | 35L(φ318*450)mm | 50L(φ340*550)mm | 75L(φ400*600)mm | 100L(φ440*650)mm |
Working pressure | 0.22Mpa | |||
Working temperature | 134℃ | |||
Max working pressure | 0.23Mpa | |||
Temperature range | 0-134℃ | |||
Timer scope | 1-99min | |||
Heat average | ≤±1℃ | |||
Power | 2.5KW/AC220V.50HZ | 3KW/AC220V.50HZ | 4.5KW/AC220V.50HZ | 4.5KW/AC220V.50HZ |
Exterior size(mm) | 600*410*1030 | 690*470*1140 | 730*510*1270 | 750*550*1305 |
Packing size(mm) | 730*500*1170 | 760*550*1290 | 820*600*1138 | 840*640*1410 |
G.W/E.W | 96/77kg | 120/100kg | 140/118kg | 160/128kg |
Model | FSF-35HV | FSF-50HV | FSF-75HV | FSF-100HV |
Capacity | 35L(φ318*450)mm | 50L(φ340*550)mm | 75L(φ400*600)mm | 100L(φ440*650)mm |
Working pressure | 0.22Mpa | |||
Working temperature | 134℃ | |||
Max working pressure | 0.23Mpa | |||
Temperature range | 0-134℃ | |||
Timer scope | 1-99min | |||
Heat average | ≤±1℃ | |||
Power | 2.5KW/AC220V.50HZ | 3KW/AC220V.50HZ | 4.5KW/AC220V.50HZ | 4.5KW/AC220V.50HZ |
Exterior size(mm) | 600*410*1030 | 690*470*1140 | 730*510*1270 | 750*550*1305 |
Packing size(mm) | 730*500*1170 | 760*550*1290 | 820*600*1138 | 840*640*1410 |
G.W/E.W | 96/77kg | 120/100kg | 140/118kg | 160/128kg |
