Technical Specification:
Application: Embroidery on light-, medium-, and heavy-weight materials
Max Sewing Speed: Max. 2,000 sti/min (zigzag width up to 10 mm), Normal: 1,700 sti/min (zigzag
width up to 12 mm)
Needle Bar Stroke:33.4 mm
Needle: DB×1 (#9–#18), standard #11
Zigzag Width:0 – 12 mm
Zigzag Adjustment: Using the jut-type knee lifter with the zigzag width pointer released
Hook: DB-type hook (for embroidery)
Lubrication: Centralized (oil lubrication system)
Material Handling Space:270 mm (from needle entry to bottom of the arm)
