FTC1000-S,FTC1000-G
FAITHFUL
FTC1000-S
• Reliable heating/cooling elements and precise temperature control
• Unique design of block ensur es the temperature uniformity and repeatable results
• 7 inch Large color touch panel screen for easy programming with user friendly software
• High performance DSP and temperature control
• Fast heating and cooling rate
• Large user program storage
TC1000-G
• Reliable heating/cooling elements and precise temperature control
• Unique design of block ensur es the temperature uniformity and repeatable results
• 7 inch Large color touch panel screen for easy programming with user friendly software
• High performance DSP and temperature control
• Fast heating and cooling rate
• Large user program storage
FTC1000-S
• Reliable heating/cooling elements and precise temperature control
• Unique design of block ensur es the temperature uniformity and repeatable results
• 7 inch Large color touch panel screen for easy programming with user friendly software
• High performance DSP and temperature control
• Fast heating and cooling rate
• Large user program storage
TC1000-G
• Reliable heating/cooling elements and precise temperature control
• Unique design of block ensur es the temperature uniformity and repeatable results
• 7 inch Large color touch panel screen for easy programming with user friendly software
• High performance DSP and temperature control
• Fast heating and cooling rate
• Large user program storage
Specifications | FTC1000-S | FTC1000-G |
Sample Capacity | 96X0.2mL PCR tube, 8X12 PCR plate or 96 well plate | 96X0.2mL PCR tube, 8X12 PCR plate or 96 well plate |
Heating Temperature Range | 4-105℃ | 4-105℃ |
Lid Temperature Range | 30-110℃ | 30-110℃ |
Temperature Display Accuracy | ±0.1℃ | ±0.1℃ |
Temperature Control Accuracy [at 55℃] | ±0.3℃ | ±0.3℃ |
Temperature uniformity [at 55℃] | <0.3℃ | <0.3℃ |
Max. Heating/Cooling Rate | 3℃/Sec | 3℃/Sec |
Gradient Temperature Setting Range | / | 30-99℃ |
Gradient Range | / | 1-42℃ |
Adapter block material | aluminum | aluminum |
Display | 7” LCD 800x480 | 7” LCD 800x480 |
Input | Touch panel | Touch panel |
User defined file system | Max.30segments 99 cycles max. 16 folder and 16 files each folder | Max.30segments 99 cycles max. 16 folder and 16 files each folder |
Power off protection | Yes | Yes |
Power Supply | 100-120V/200-240V,50/60Hz | 100-120V/200-240V,50/60Hz |
Dimension [D×W×H] ( without the heating block ) | 280x370x250 mm | 280x370x250 mm |
Weight | 11kg | 11kg |
Specifications | FTC1000-S | FTC1000-G |
Sample Capacity | 96X0.2mL PCR tube, 8X12 PCR plate or 96 well plate | 96X0.2mL PCR tube, 8X12 PCR plate or 96 well plate |
Heating Temperature Range | 4-105℃ | 4-105℃ |
Lid Temperature Range | 30-110℃ | 30-110℃ |
Temperature Display Accuracy | ±0.1℃ | ±0.1℃ |
Temperature Control Accuracy [at 55℃] | ±0.3℃ | ±0.3℃ |
Temperature uniformity [at 55℃] | <0.3℃ | <0.3℃ |
Max. Heating/Cooling Rate | 3℃/Sec | 3℃/Sec |
Gradient Temperature Setting Range | / | 30-99℃ |
Gradient Range | / | 1-42℃ |
Adapter block material | aluminum | aluminum |
Display | 7” LCD 800x480 | 7” LCD 800x480 |
Input | Touch panel | Touch panel |
User defined file system | Max.30segments 99 cycles max. 16 folder and 16 files each folder | Max.30segments 99 cycles max. 16 folder and 16 files each folder |
Power off protection | Yes | Yes |
Power Supply | 100-120V/200-240V,50/60Hz | 100-120V/200-240V,50/60Hz |
Dimension [D×W×H] ( without the heating block ) | 280x370x250 mm | 280x370x250 mm |
Weight | 11kg | 11kg |
